Install Android 10 Q LineageOS 17 on OnePlus 5

Download Android 10 based LineageOS 17 custom ROM on OnePlus 5 cheeseburger smartphone. This year Google unveiled Android Q as the 10th version of Android OS. Google Pixel devices were the first smartphones featuring this Android 10 operating system. Soon after the update was released, the Lineage OS team began developing their famous third party custom firmware. In this easy steps guide, we’ll download and install Android Q based LineageOS 17 ROM on OnePlus 5.

Android 10 Q based Lineage OS 17 ROM on OnePlus 5
LineageOS 17 is based on the latest Android 10 update. As we all know, Lineage OS is the most popular custom ROM after CyanogenMod. Almost every other smartphone supports the Lineage OS. Besides, you can get frequent Lineage OS updates with more unique and enhanced features with each update. This Lineage OS 17 update for OnePlus 5 is developed by codeworkx, a recognized member from the CyanogenMod community. By flashing this LineageOS 17 ROM on OnePlus 5, you can experience all the latest Android Q features as well as Lineage OS 17 features.

Android Q comes with plenty of new features. Some of which includes new system UI, native theme, Wi-Fi direct printing, systrace Android studio tool, native support for specialized DNS lookups, adaptive battery with AI support, call recording tone support and much more. Besides, OnePlus 5 launch date in India was June 2017. Most important, this device was released with Android Nougat which was later upgraded to Android 9.0 Pie. However, there are quite chances that the company will never release the official Android 10 update for OnePlus 5.

Hence, in order to enjoy the Android Q update, you can now install Lineage OS 17 ROM using our easy steps guide. This Lineage OS ROM is completely stable with no bugs or issues. Unfortunately, if you come across any bugs, then don’t worry. All those issues will be wiped out as frequent updates are being rolled out for this device. Do you want the best custom ROM for OnePlus 5? Then you are at the right place. Interested users may move ahead to our actual tutorial on how to install Android Q ROM on OnePlus 5 cheeseburger smartphone.

Disclaimer:

Proceed at your own risk. Neither we at Droid Thunder nor the developers of this ROM will be held responsible for any of the damage caused to your phone after following this guide.

Compatibility:

Install this Android 10 based Lineage OS 17 ROM only on OnePlus 5 (cheeseburger). Do not flash this unofficial custom firmware on any other device or variant as it might cause permanent damage. Hence confirm your device model before going further.

Screenshots:

Android 10 Q ROM on OnePlus 5 screenshot 1
Android 10 Q ROM on OnePlus 5 screenshot 2
Android 10 Q ROM on OnePlus 5 screenshot 3

Pre-Requisites:

  • Charge your phone to at least 50% before going ahead.
  • Backup your contacts, messages, apps, call logs, notes etc. This is necessary as everything gets wiped out in the last step of this procedure.
  • Install latest OnePlus USB drivers on your PC so as to detect your mobile when connected through USB cable.
  1. Download OnePlus 5 USB drivers.
  • Enable USB debugging mode in your phone settings. Refer our guide:
  1. How to Enable USB Debugging on OnePlus 5.
  • Moreover, unlock bootloader on OnePlus 5 before moving ahead. Refer:
  1. How to Unlock Bootloader of OnePlus 5.
  • Also install latest TWRP recovery on OnePlus 5. Refer our guide:
  1. How to install TWRP on OnePlus 5.
  • It is essential to root Android phone before flashing ROM. Refer our guide:
  1. How to Root OnePlus 5.

After doing everything as given above, go to our OnePlus 5 Android 10 ROM installation guide.

Steps to install LineageOS 17 ROM on OnePlus 5:


Step 1: Download LineageOS 17 ROM.

Step 2: Download GApps.

Note: Do not extract these zip files.

Step 3: Connect your OnePlus 5 to PC and copy both the downloaded zip files on your mobile storage.

Note: If you don’t have PC, then directly download the files on your phone.

Step 4: Power off your phone. Then boot it into TWRP recovery mode.

Step 5: For doing that, press and hold Volume down + Power button simultaneously. Leave both the keys as soon as you see the TWRP logo.

Note: If you are not able to boot phone into recovery, use TWRP manager app from Google Play Store.

This is how you can reboot OnePlus 5 into TWRP recovery mode.

Step 6: As soon as you boot into TWRP, take Nandroid backup first. This is the backup of your entire Android OS. Refer our guide:

  1. How to take Nandroid Backup on OnePlus 5.

Step 7: After taking Nandroid backup, tap on Wipe button from the TWRP main menu screen.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Step 8: Then swipe right to start the wiping process.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Note: This step will wipe out your complete phone data and settings. Hence take backup before performing this step.

Step 9: Go back to main screen and again select the Wipe option.

Step 10: On the next screen, select the Advanced Wipe option.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Step 11: Then select Dalvik / ART cache, System, Data and cache partitions.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Note: Do not select any other partitions other than the mentioned ones.

Step 12: Now swipe right to start the wiping process.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Let’s start the OnePlus 5 LineageOS 17 ROM installation process now.

Step 13: For doing that, select the Install option from the TWRP main menu.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

All the files and folders present on your phone storage will appear.

Step 14: Just navigate and select the downloaded LineageOS 17 ROM which you’ve copied earlier.

On the next screen, swipe right to start the OnePlus 5 Lineage OS ROM installation process.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q
Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

The Lineage OS ROM flashing process will hardly last for few minutes. So be patient and wait.

Step 15: Similarly install the Google Apps (GApps) zip package file.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q
Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q
Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Step 16: Finally, everything finishes here. Simply select Reboot » System option to restart your phone.

Install LineageOS 17 custom ROM on OnePlus 5 via Android 10 Q

Note: The first boot will take more time to start than usual. But don’t panic as everything will be normal after a couple of boots.

I hope this guide helped you to install Android 10 Q based LineageOS 17 custom ROM on OnePlus 5 (cheeseburger) smartphone. If in case you come across any problem then without hesitation kindly contact us. We’ll help you out as soon as possible.

Till then Spread Love and Keep Smiling.
Peace out! ✌
