Install Android 8.1.0 Oreo official software update on Samsung Galaxy M30 SM-M305F smartphone. Soon after the launch of Galaxy M10 and Galaxy M20, Samsung rolled out an upgraded version of the M series. Samsung Galaxy M30 which is the third variant comes with a triple camera support and 6.3 inch full HD + Super AMOLED Infinity-U display. Although Galaxy M30 launch date in India was February 27th 2019, it already became famous due to its amazing specs and features.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update
In particular, if you compare Galaxy M10 vs M20 vs M30, the third version of this M series will easily win the comparison. Galaxy M30 specs include Exynos 7904 octa-core processor and non-removable Li-Po 5000 mAh battery. It comes in two variants: 128 GB, 6 GB RAM and 64 GB, 4 GB RAM. Besides, Galaxy M30 features 13 + 5 + 5 megapixel triple camera. On the other hand, it sports 16 megapixel front camera for selfies. To check out more detailed specifications, search for Galaxy M30 gsmarena on web.

Related: How to Root Samsung Galaxy M30.

Talking about the Galaxy M30 review, this device is the best mid range phone with high end specifications. Galaxy M30 64GB price starts from Rs. 14,990 whereas Galaxy M30 128GB price starts from Rs. 17,990. In this tutorial, we will manually flash latest Android Stock ROM on Samsung Galaxy M30 using Odin3-v3.13 tool. Remember that this is an Indian (INS) OTA update with January 2019 security patch. Also note that this is not any third party custom ROM.

This firmware is based on Android version 8.1.0 Oreo with build number M305FDDU1ASBA. It is quite sure that Samsung will release Galaxy M30 Android Pie update in coming weeks. But till then, you can download Galaxy M30 software update using steps mentioned ahead. Here we give  Samsung firmware Google Drive link for fast download. Interested users can proceed to our guide on how to update Galaxy M30 to Android 8.1.0 Oreo firmware given below.

About Firmware:

Model Name: Samsung Galaxy M30
Model Number: SM-M305F
OS Version: Android 8.1.0 Oreo
Build Date: 27 February, 2019
Region: India (INS)
PDA Version: M305FDDU1ASBA
CSC Version: M305FODM1ASBA
MODEM Version: M305FDDU1ASBA

Disclaimer:

This process is risky and can damage your device completely. Hence it is recommended to perform all the steps at your own risk. Moreover, the firmware used is property of their respective owners.

Compatibility:

This firmware is only for Samsung Galaxy M30 with model number SM-M305F. Flashing this Stock ROM update on any other mobile can damage it. It’s better to confirm your device model before going ahead.

Screenshots:

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Pre-Requisites:

  • To avoid any interruption, charge your phone at least 60%.
  • Backup contacts, apps, messages, call logs, notes etc. Use any backup app from Google Play Store.
  • Install Samsung USB drivers on PC so as to detect your device when connected using USB cable.
  1. Download latest Samsung USB Drivers.
  • (Optional) Temporary disable all the security tools as well as antivirus on your PC.

Steps to install Android 8.1.0 Oreo on Galaxy M30:


Step 1: Download Android 8.1.0 Oreo firmware.

Step 2: Next extract the downloaded INS-M305FDDU1ASBA.zip firmware file on PC.

Step 3: Switch off your device and boot it into downloading mode.

Step 4: For that, press and hold Volume Down key + Power Button simultaneously.

Leave both the keys as soon as you see the following warning message.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Step 5: Press Volume Up button.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

This will boot Samsung Galaxy M30 into Download Mode.

Step 6: Keeping the mobile in download mode, connect it to PC.

Step 7: Download Odin3-v3.13.1.

Step 8: Launch the downloaded ‘Odin Multi Downloader3-v3.13.1′ tool.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Now check whether the ID: COM section in Odin window is turned light blue or not. Also check if an Added message is appeared in the message box window or not.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Note: If such thing does not happen then it’s more likely to be problem with mobile drivers. So install latest USB drivers from the links given in Pre-Requisites section. If the problem still persists, change USB cable or port.

Step 9: Then check Auto Reboot and F.Reset Time under Options tab.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Step 10: Let’s add firmware files one by one in the Odin window. For that, click on BL button present on the Odin window and select file with ‘BL’ in it’s name.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Step 11: Similarly click on CP button and select file with ‘CP’ in its name.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Step 12: Next click on CSC button and select file with ‘HOME_CSC’ in its name.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

Note: HOME_CSC contains instruction that allows Odin to only wipe cache while Normal CSC contains an instruction to wipe out complete data. But when a downgrade is done (example: from Oreo back to Nougat) a factory reset is must. So use normal CSC at that time.

Step 13: Lastly click on AP button and select file with ‘AP’ in its name.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

Note: The AP file will take little time to load.

Step 14: Let’s initiate the firmware flashing process. For doing so, press the Start button from the Odin window.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

This will start the actual Android 8.1.0 Oreo firmware flashing process.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

Note: Your mobile will boot itself automatically. Do not disconnect your phone from computer.

Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software Odin update

After the flashing process completes, the ID: COM tab will change its color to green with a message ‘Pass’ on it. This will confirm that your Samsung Galaxy M30 SM-M305F is successfully upgraded to official Android 8.1.0 Oreo M305FDDU1ASBA Stock firmware.

Update Samsung Galaxy M30 to Android 8.1.0 Oreo firmware software update

Note: If Odin fails to install this Stock firmware on your phone, then close the Odin tool, again go into downloading mode and repeat the complete procedure again.

Finally! The latest official Android 8.1.0 Oreo DDU1ASBA firmware is successfully flashed on your Samsung Galaxy M30 SM-M305F smartphone. To verify the same, navigate to Menu->Settings->About Phone. Enjoy and experience the all new Oreo features on your device. Also don’t forget to share your views with us.
