Update Galaxy M20 to official Android 8.1.0 Oreo firmware. This is the first time Samsung has launched new phones with the most current January 2019 security patch. We will soon see Android Pie update as well as Android Q update for Galaxy M10 and M20 smartphones. As per Galaxy M20 review from Samsung, it seems that this mid range smartphone is undoubtedly the best mobile phone of 2019. Galaxy M20 launch date in India was January 28th 2019. But it became available online from February 5 onward.

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

You can see various Galaxy M20 unboxing videos on YouTube. Galaxy M20 accessories include travel adapter charger 9V 1.67 Amp, USB Type C cable, SIM card eject tool, warranty card and manual guide. There are only few differences between Galaxy M10 vs M20. It is quite obvious that Galaxy M20 specs are slightly better than Galaxy M10. Galaxy M20 price in India starts from Rs. 12,990. But you won’t believe Galaxy M20 sale will start from February 5th, so you can buy from Amazon online website. Samsung Galaxy M20 competitors & rivals include Xiaomi, Oppo F11 Pro, Huawei Y6 2019, Motorola Moto G7 Play, Huawei nova Lite 3, Huawei Y7 Prime 2019, Asus Zenfone Max Pro M2, Ulefone Armor X, Infinix Note 4 and Panasonic Eluga Ray 700.

Let’s checkout some of the Galaxy M20 specs now. This M series smartphone include 6.3 inches screen with 1080 x 2340 pixels of resolution. The most amazing thing is that Galaxy M20 features a dual camera setup which includes a 13 megapixel primary lens and a 5 megapixel wide angle lens. Galaxy M20 battery has a massive 5,000mAh power with fast charging support. Talking about Galaxy M20 processor, it comes with octa-core processor with 4 GB RAM and 64 GB internal memory. It also comes with Android 8.1 Oreo out of the box. For full phone specifications, search galaxy M20 gsmarena on Google. So today, we will manually install latest official Android 8.1.0 Oreo based Stock ROM on Samsung Galaxy M20 using Odin software.

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

Note that this is an Indian (INS) OTA update official from Samsung. And it is not any third party custom firmware. Hence your phone warranty will not get void after flashing this Stock ROM. In fact, there are various device stability improvements, enhancements and bug fixes. This update is based on Android version 8.1.0 Oreo with build number M205FDDU1ASAF. Go ahead to download Galaxy M20 software update using easy steps guide mentioned below. Here we give direct Samsung firmware Google Drive links for fast download. If you want to root Galaxy M20 without PC, then stay tuned as we will soon post a tutorial on that.

About Firmware:

Model Name: Samsung Galaxy M20
Model Number: SM-M205F
OS Version: Android 8.1.0 Oreo
Build Date: 30 January, 2019
Region: India (INS)
PDA Version: M205FDDU1ASAF
CSC Version: M205FODM1ASA9
MODEM Version: M205FDDU1ASAE

Disclaimer:

Proceed at your own risk. If your phone gets damaged by following this guide, then we at Droid Thunder will not be held responsible for that. Moreover, the firmware used is property of their respective owners.

Compatibility:

This Android 8.1.0 Oreo M205FDDU1ASAF software update must be flashed only on Samsung Galaxy M20 having model number SM-M205F. Installing this firmware on any other device or variant can be dangerous.

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

Pre-Requisites:

  • To avoid any interruption, it is recommended to charge your phone at least 60%.
  • This flashing process will delete your phone data completely. Hence backup your contacts, apps, messages, call logs, notes etc.
  • Install latest Samsung USB drivers on PC so as to detect your phone when connected using USB cable.
  1. Download latest Samsung USB Drivers.
  • (Optional) Temporary disable all the security tools as well as antivirus on your computer.

Steps to update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware:

Step 1: Download Android 8.1.0 Oreo on PC.

Step 2: Extract the downloaded INS-M205FDDU1ASAF.zip firmware file. You’ll see these files after extraction:

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

Step 3: Switch off your device completely.

Step 4: Boot your Galaxy M20 into Download Mode. For that, press and hold Volume Down key + Power Button simultaneously.

Leave both the keys as soon as you see a warning message on the screen.

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

Step 5: Press Volume Up button.

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

This is how you can boot Samsung Galaxy M20 into Download Mode aka Odin Mode.

Step 6: Keeping the phone in downloading mode, connect it to your computer via USB cable.

Step 7: Download Odin3-v3.13.1 on PC.

Step 8: Open the downloaded ‘Odin Multi Downloader3-v3.13.1′ tool.

Update Samsung Galaxy M20 to Android 8.1.0 Oreo firmware software update

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin tool

Now we will verify whether your phone is connected to computer or not. So check the ID: COM section in the Odin window is turned light blue or not. Also check if an Added message is appeared in the message box window or not.

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 1

Note: If such thing does not happen then it’s more likely to be problem with Samsung USB drivers. So again install latest USB drivers from the links given above. If the problem still persists, try changing USB cable or your computer.

Step 9: Under Options tab, tick the Auto Reboot and F.Reset Time options . Do not tick Nand Erase or Re-Partition options.

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 2

Let’s add the firmware files in the Odin tool.

Step 10: So click on the BL button present on the Odin window and select the ‘BL_M205FDDU1ASAF_CL15095373_QB21826129_REV03_user_low_ship.tar.md5’ from the extracted firmware package file.

Samsung Galaxy M20 Android 8.1.0 Oreo firmware BL file

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 3

Step 11: Similarly click on the CP button and select the ‘CP_M205FDDU1ASAE_CL1029438_QB11764333_SIGNED.tar.md5’ file.

Samsung Galaxy M20 Android 8.1.0 Oreo firmware CP file

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 4

Step 12: Then click on CSC button and select the ‘HOME_CSC_OMC_ODM_M205FODM1ASA9_CL15095373_QB21605981_REV03_user_low_ship.tar.md5’ file.

Samsung Galaxy M20 Android 8.1.0 Oreo firmware CSC file

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 5

Note: HOME_CSC contains instruction that allows Odin to only wipe cache while Normal CSC contains an instruction to wipe out complete data. But when a downgrade is done (example: from Oreo back to Nougat) a factory reset is must. So use normal CSC at that time.

Step 13: Lastly hit the AP button and select the ‘AP_M205FDDU1ASAF_CL15095373_QB21826129_REV03_user_low_ship_meta_RKEY.tar.md5’ file.

Samsung Galaxy M20 Android 8.1.0 Oreo firmware AP file

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 6

Note: The AP file will take little time to load. So be patient.

Step 14: We will now initiate the firmware flashing process. So tap on the Start button.

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 7

This will begin the Android 8.1.0 Oreo firmware flashing process.

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 8

Note: Your phone will automatically boot itself. Do not disconnect your phone from computer.

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 9

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 10

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 11

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 12

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 13

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 14

After the flashing process completes, the ID: COM section will turn green with a message ‘Pass’ on it. This will confirm that your Samsung Galaxy M20 is successfully upgraded to latest official Android 8.1.0 Oreo M205FDDU1ASAF firmware. Now you can safely remove USB cable and disconnect your phone from computer.

Install Android 8.1.0 Oreo firmware software update on Samsung Galaxy M20 using Odin 15

Note: If Odin fails to flash Stock ROM on your device, then close the Odin tool, again go into downloading mode and repeat the complete procedure again.

Finally! The latest official Android 8.1.0 Oreo DDU1ASAF firmware is successfully installed on your Samsung Galaxy M20 SM-M205F. To confirm the same, go to Menu->Settings->About Phone. For any queries related to this article, kindly comment below.

Till then spread love and keep smiling.

Peace out! ✌
